X Comp A/T

Light Truck / Highway / Off Road / Performance
  • This new cutting edge tire design has all the advantages of the X Comp M/T and ATR, with some very subtle changes.
  • The tire casing has two full plies of polyester with full sidewall turn up, to enable a more comfortable ride, yet very strong and durable.
  • Features

    Tire Design and Construction Advantages

    • This new cutting edge tire design has all the advantages of the X Comp M/T and ATR, with some very subtle changes.
    • The tire casing has two full plies of polyester with full sidewall turn up, to enable a more comfortable ride, yet very strong and durable.
    • The tread area is an aggressive design, yet suitable for everyday driving conditions, with all season and snow flake ratings!
    • The tire shoulder area incorporates X Comp’s proven aggressive and functional design, giving drivers protection and traction when needed.
    • In summary, this new tire is very quiet with a smooth controlled ride for all driving conditions on and off road.
  • Specifications
    SizePly RatingLoad Index (S/D)Speed SymbolTread Depth (32nds)Overall Diameter (In)Section Width (In)Load Capacity (S/D) LBS
    LT235/75R1510116/113S1628.99.32755/2535
    LT235/70R168110/107S1629.09.42335/2150
    LT235/85R1610120/116S1631.79.33085/2755
    LT245/70R1610118/115S1629.59.82910/2680
    LT245/75R1610120/116S1530.59.83085/2755
    LT265/70R1610121/118S1630.610.73195/2910
    LT265/75R1610123/120R1531.710.53415/3085
    LT275/70R168119/116S1631.211.03000/2755
    LT285/75R1610126/123Q1632.811.33750/3415
    LT235/80R1710120/117R1531.89.33042/2835
    LT245/70R1710119/116S1630.69.83000/2755
    LT245/75R1710121/118S1531.59.83195/2910
    LT265/65R1710120/117S1630.610.73085/2835
    P265/70R17-113S1331.710.72535
    LT265/70R1710121/118S1631.710.73195/2910
    LT285/70R1710121/118Q1632.811.53195/2910
    33X12.50R17LT10126Q1632.512.53750
    35X12.50R17LT10126Q1634.512.53750
    37X13.50R17LT10131Q1636.513.64300
    40X13.50R17LT10131Q1639.513.64300
    LT235/60R188108/104S1629.19.42205/1985
    LT265/60R1810119/116S1630.510.73000/2755
    LT275/65R1810123/120Q1632.111.03415/3085
    LT285/60R1810122/119S1631.511.53305/3000
    33X12.50R18LT10118Q1632.512.52910
    35X12.50R18LT10123T1634.512.53415
    P275/55R20 XL-117T1331.911.22835
    LT275/65R2010126/123S1534.111.03750/3415
    LT285/55R2010122/119Q1632.411.73305/3000
    LT285/65R2010127/124Q1634.611.53860/3525
    33X12.50R20LT10114Q1632.512.52600
    35X12.50R20LT10121T1634.512.53195
    37/13.50R20LT10127Q1636.513.63860
    40X13.50R20LT10128Q1639.513.63970
    P285/45R22 XL *-114H1332.111.22601
  • Warranty

    GLADIATOR X-COMP TIRES LIMITED WARRANTY

    100% FREE REPLACEMENT WARRANTY

    American Pacific Industries, Inc (API) hereby warrants every new Gladiator XCOMP tire for workmanship and material related conditions for the life of the original tread of a new tire less 2/32”. The life of the original usable tread ends when the tire tread has worn down with only 2/32” remaining as measured in the fastest wearing groove, at which point the tire is considered to be fully worn out. API will replace the Gladiator XCOMP tire with a new Gladiator XCOMP tire. All Exclusions listed below void this 100% Free Replacement Warranty. Conditions and coverage are subject to change at any time and without notice.
        A) The worn Gladiator XCOMP tire must be replaced with a comparable new Gladiator XCOMP tire by an authorized Gladiator XCOMP dealer. Copy of invoice will be required.
        B) 100% free replacement applies to new first quality tires only. Retreads, tires unserviceable due to Road Hazard and tires described under Exclusions below are not covered.
        C) Adjustments on ride complaints or out of round tires are excluded from this warranty if they are worn past 2/32” from the original usable tread of the new tire.

    SATISFACTION ASSURED

    All API passenger and LT tires are covered by the 30 Day “Satisfaction Assured” trial period. If, for any reason, other than an excluded condition listed in the respective tire’s Standard Warranty, you are not satisfied with your new set of tires within 30 days of date of purchase – or the first 2/32nds of tread wear as measured in the fastest wearing groove (whichever comes first) – you may exchange all or any one of them for the same number of the same design or similar design API manufactured tires. Mounting and balancing are free of charge (excluding online orders). Owner pays all applicable taxes. If you wish to exchange for another set of API manufactured tires that have a higher cost, you must pay the upgrade from the original purchase price, including shipping and all applicable taxes. If you wish to exchange for another set of tires, which is at a lower cost, you will receive a credit (excluding FET) for the difference in cost. This Satisfaction Assurance guarantee only applies to the original new set of manufactured passenger and LT tires purchased and not to the replacement tires under this guarantee.

    Administration of the Assured Satisfaction Warranty

    Within the 30 days from the date of purchase or the first 2/32nds tread wear as measured in the fastest wearing groove, you must return your tires to the authorized API brand tire dealer where you purchased your tires. You must present the original sales receipt and proof-of-purchase. Reason for dissatisfaction must be explained to the dealer (i.e., appearance, ride, handling, etc.) and noted on the adjustment claim form.

    EXCLUSIONS

        A) All Gladiator XCOMP warranties are limited to the original purchaser and the original vehicle on which they are mounted, and are not assignable to subsequent purchasers or vehicles.
        B) The warranties listed above are applicable only in the United States and Canada and any tire used or equipped on a vehicle registered or operated outside the United States and Canada are not covered by these warranties.
        C) The following is not covered by the warranties listed above:
            1) Tire branded or marked “Non-Adjustable” (N/A) or “Blemished” (Blem), or previously adjusted.
            2) Failure, damage or irregular wear due to:
                a) fire, accident or vandalism;
                b) mechanical condition of vehicle, including improper alignment, improper inflation, wheel imbalance, faulty shocks or brakes;
                c) misapplication of tire; or
                d) alteration of the tire, addition of foreign material, transfers from one vehicle to another or any previous damages and/or repairs.
            3) Cost of mounting and balance service.
            4) Loss of time or use, inconvenience, or any incidental or consequential damages except as prohibited by law.
            5) Adjustment on out-of-balance or out-of-round tires are allowed only during the first 2/32” of the original tread. A set of all four (4) tires from the same vehicle claimed for out-of-round will not be accepted.
        D) Any Gladiator XCOMP tire submitted five (5) years or more from the date of manufacture as determined by the DOT Serial number is not covered under the warranties listed above.

    REPAIRS AND RETREADING: RATING CHANGES AND CAUTIONS

        A) Repaired, retreaded or altered Gladiator XCOMP tire with “Speed Rating” no longer retain their “Speed Rating”.
        B) If the aforementioned tire(s) is repairable, see the recommended repair procedures used by the tire dealer(s) for repairing tubeless passenger car radial tires as detailed and illustrated in the RMA puncture repair procedures.
        C) Repairs must be restricted to the tread area inside a half inch of the sidewall of the tire.
        D) Do not repair any sidewall punctures and/or tread area punctures that are larger than 1/4” in diameter.

    OWNER’S OBLIGATIONS

    In order to be eligible for Gladiator XCOMP Limited Warranty service, the dealer/owner must:
        A) At the time of purchase, the tires must be properly installed, correct air pressure set and the wheels balanced. Every 6,000 miles the tires must be rotated, proper air pressures set and the wheel alignment checked.
        B) Any tire to be adjusted must be presented to an authorized Gladiator XCOMP dealer.
        C) Present proof of purchase to the satisfaction of the dealer.
        D) Complete and sign a Gladiator XCOMP Warranty Claim Form which is available at any authorized dealer.
        E) Pay the amount due on taxes, mounting and balancing charges or cost of other services ordered.

    DISCLAIMER

    This warranty, or any warranty stated or referred to herein, is exclusive and in lieu of any other warranty regarding the quality of Gladiator XCOMP Tires, whether expressed or implied, and remedies for breach thereof shall be limited to those specifically provided herein.

  • Dealers
